PHH series slurry pump
PHH series slurry pump
PHH pumps can also be called heavy slurry pumps. Because this type of pump has thick wear parts and heavy bracket, it is suitable for conveying strong abrasion, high concentration slag slurry or low concentration high lift slag slurry.
Category:
Keywords:
PHH series slurry pump
E-mail：
- 产品描述
-
Product Description
PHH pumps can also be called heavy slurry pumps. Because this type of pump has thick wear parts and heavy bracket, it is suitable for conveying strong abrasion, high concentration slag slurry or low concentration high lift slag slurry. It can be used in series at multiple levels within the maximum allowable working pressure range of the pump. HH pump is suitable for conveying low concentration high head slag slurry or high concentration low abrasive high head pump.
Technical Parameters
TYPE MAX. POWER
(kw)CLEAR WATER PERFORMANCE IMPELLER CAPACITY
QHEAD
H(m)SPEED
n(r/min)MAX.EFF
η(%)NPSHr
(m)NUMBER DIA.
(mm)(m3/h) (L/S) PHHC-40 30 16.2-34.2 4.5-9.5 25-92 1400-2200 20 2-5.5 5 330 PHHD-75 60 68.4-136.8 19-38 25-87 850-1400 47 3-7.5 5 457 PHHE-100 120 126-252 35-70 12-97 600-1400 50 2-5 5 508 PHHS-150 560 324-720 90-200 30-118 600-1000 64 3-8 5 711 PHHS-150 560 468-1008 130-280 20-94 500-1000 65 4-12 5 711 Product Diagram
